| Selection of |
Kg/Cm2, Bar, PSI, KPa, mm WC, |
| Engineering Units : |
mm Hg, In WC, In Hg |
| Enclosure : |
Aluminium Anodised, Light Weight / SS 304 |
| Display : |
8 x 2 Dot matrix display, shows Pressure, unit & low batt. |
| Media : |
It works with any media that will not adversely affect SS 316 |
| Accuracy : |
± 0.15% & 0.5% or better of full scale at calibrated temperature |
| Power : |
Standard 9 V 150 mAh, Ni MH with charger or 230 VAC, 50 Hz |
| Connection : |
1/4 BSP Male (others on request) |
| Over pressure : |
130% of specified range |
| Temperature : |
Storage : -40 to 85°C |
| Operating : |
-40 to 85°C |
| 4-20 mA : |
Available (Optional) |
| SPDT Relay output : |
Available (Optional) Provides 2 adjustable SPDT relay |
| Diaphragm seals : |
Various size, style and MOC available |
