CONSTRUCTION FEATURES
Enclosure : | Die Cast Aluminum |
---|---|
Protection : | IP, Flameproof Grade IIA, IIB & IIC |
Sensor Element : | J, K, E, T, N ( Simplex or Duplex ) J ( Fe-CuNi)- 800° C K ( Nicr - Ni )- 1200° C E ( Nicr - CuNi )- 800° C T ( Cu - CuNi ) - 400° C N ( NiCrSi-NiSi)- 1200° C |
Cold End : | Terminated in to ceramic terminal block |
Stem Material : | SS 316 / SS 304, Inconel, Monel, Haystalloy | Stem Dia. : | 6mm, 8mm, 10mm & 12mm | Stem Length : | 300mm Standard | Hot Junction : | Ungrounded unless specified | Configuration : | 2 wire, 3 wire & 4 wire | Connection : | ¼", 3/8", ½" BSP / NPT Adjustable. | Range : | 0°C to 1200°C |
OPTIONAL FEATURES :
• Head mounted transmitter can be mounted
• 'L' Shape or any other shape available on request.
APPLICATION : Machinery, Plant & Tank, Construction, energy & power plant,chemical industries, Sanitary, heating & air conditioning.
