CONSTRUCTION FEATURES
| Dial Size : | 63mm, 100mm & 150mm. |
|---|---|
| Accuracy : | + 1.6% of full scale. |
| Case & Bezel (IP-65) : | SS 304 Snap Action Bayonet type & SS 304 Press Fit Type. |
| Temp. Element : | Wounded coil of Bimetal. |
| Stem & Bulb : | SS 304, SS 316 ( 6mm, 8mm, 10mm & 12mm ). | Stem Length : | SS 304, SS 316 ( up to 300mm ). | Dial : | Aluminum white painted with 270 degree black scale marking . | Pointer : | Brass with black finish. | Window : | Plain Glass / Toughened / Safety glass. | Joints : | Argon arc welded. | Mounting : | Stem (Bottom), Back & Every angle. | Connection : | ¼" / 3/8" / ½" BSP / NPT ( Fix or Adjustable ). | Scale Range : | -30 to 50° to 500° C or equivalent in °F |
BIMETAL TEMP. GAUGES OPTIONAL FEATURES :
• Dual scale °C & °F available on request.
• Every angle mounting available on request.
• Extra stem length on request,
• TC Connection on request.
BIMETAL TEMP. GAUGES APPLICATION : Domestic & industrial heating system, hot water boiler, power plant, food & beverage industries, pharmaceutical industry etc.
